QUICRUN Brushless System

Brushless ESC
[see below]
BRUSHED ESC


Features

Water-proof and dust-proof for all-weather races.

Want to drive during tough weather like pro racers?  With our QucRUN brushless series, you no longer need a traditional waterproofing box.  Our ESC is completely waterproofed so that you can save not only space in a compartment but also the weight of the vehicle.



External programming port

External programming port allows you easy to connect to HOBBYWING Program Card when setting the ESC anytime, anywhere. With the portable-Digital LED Program Card, especially convenient for outdoor use.


Proportional Braking & Acceleration enable

QuicRun enables you 4 steps of maximum brake force adjustment and 8 steps of drag-brake force adjustment,  9 steps of acceleration (/punch) adjustment from “soft” to “VA" -Very aggressive.  These adjustments will enable you to fit for wide range of models, tires, and tracks.



Multiple protections

Low voltage cut-off protection / Over-heat protection / Throttle signal loss protection / Motor lock-up protection.



One-button to set the ESC

Simply "One-button".  That is all you need. It is also easy to reset all parameters to the factory default settings.



Compatibility

Compatible with the optional device and many more..

QUICRUN 16 QUICRUN-10 SENSORED QUICRUN 10 QUICRUN 08
SD/SL Sensorless Sensored / Sensorless Sensorless Sensorless
Waterproof Yes No Yes Yes
Cont.Current
30A 60A 60A 150A
Peak Current 180A 380A 360A 950A
Resistance 0.002Ω 0.0008Ω 0.001Ω 0.00035Ω
Car Applicable

1:18 & 1:16
On-road/Off-road/Buggy/Monster

1/10 & 1/12 On-road / Off-road
/ F1 / Drift car race
Street race for fun / Club racing /
STOCK race with 0 timing /
Drift car race

1:10
On-road/Off-road/Buggy/Monster

1:8
Buggy/Monster

Motor Limit

For 2S Lipo or 6 cells NiMH:
1. On-road: 2435-size or smaller motor with the KV<8000
2. Off-road/Buggy/Monster: 2435-size or smaller motor with the KV<5000

For 3S Lipo or 9 cells NiMH:
1. On-road: 2435-size or smaller motor with the KV<5500
2. Off-road/Buggy/Monster: 2435-size or smaller motor with the KV<3500

For 2S Lipo or 4-6 cells NiMH:
≥8.5T(1/10 On-road),
≥13.5T(1/10 Off-road) *Note 1

For 3S Lipo or 8-9 cells NiMH:
≥13.5T(1/10 On-road),
≥17.5T(1/10 Off-road)

*Note 1≥13.5T(1/10 On-road), ≥17.5T(1/10 Off-road) *Note 1
Note 1: “T” indicates the limit value of motor turns when the ESC timing is set to 0. The larger the timing, the more turns the motor needs.

For 2S Lipo or 6 cells NiMH:
1. On-road: 3656-size or smaller motor with the KV<6000
2. Off-road/Buggy/Monster: 3656-size or smaller motor with the KV<4000

For 3S Lipo or 9 cells NiMH:
1. On-road: 3656-size or smaller motor with the KV<4000
2. Off-road/Buggy/Monster: 3656-size or smaller motor with the KV<300

For 4S Lipo or 12 cells NiMH:
4274-size or smaller motor with the KV<3000

For 6S Lipo or 18 cells NiMH:
4274-size or smaller motor with the KV<2400



Battery

4-9 Cells NiMH
2-3S Lipo

4-9 cells NiMH
2-3S Lipo

4-9 Cells NiMH
2-3S Lipo

9-18 Cells NiMH
3-6S Lipo

BEC Output 6V/1A (Linear Mode) 6V@2A (Linear Mode)
(The cooling fan gets its power supply from the built-in BEC)
6V/2A (Linear Mode) 6V/3A (Switch Mode)
Size/ Weight 36(L)*28(W)*16(H)

33mm(L)*28mm(W)*31.5mm(H) with cooling fan 48.5(L)*38(W)*32(H)

59.5(L)*48(W)*42(H)

External Program Port External Program Port
Not Available
External Program Port
Available
External Program Port
Available
External Program Port
Available
Working voltage of Fan No cooling fan From BEC (6V) From battery directly without regulating From BEC (6V)
Weight 38g 59g
(with wires, without cooling Fan)
90g 178g

$24.99
Free Shipping

Available for pickup
Check authorized dealer

$52.99
Free Shipping

Available for pickup
Check authorized dealer

$45.99
Free Shipping

Available for pickup
Check authorized dealer

$99.99
Free Shipping

Available for pickup
Check authorized dealer

QUICRUN Brushless Motors

Built to Last

Composed by high-quality components: exquisite aluminum alloy motor shell, heat-resistant wires and magnets, and long-life bearings.

Efficiency

Larger torque, higher efficiency and more output power while keep the motor temperature cool*



QUICRUN 2453 QUICRUN3656 QUICRUN4074  QUICRUN3650
SENSORLESS SENSORLESS SENSORLESS SENSORED
1:16 & 1:18
On/Off-road/ Truck /Monster
1:10 & 1:12
On/Off-road/Truck/Monster
1:8
Truck/Monster
1:10 & 1:12
On/Off-road
2POLE 4POLE 4POLE 2POLE
4500kV 3800kV 2000kV 1700-3300kV
2-3S 2-3S 2-6S 2-3S
$27.49
Free Shipping

Available for pickup
Check authorized dealers
$47.99
Free Shipping

Available for pickup
Check authorized dealers
$78.99
Free Shipping

Available for pickup
Check authorized dealers

$47.99
Free Shipping

Available for pickup
Check authorized dealers

QUICRUN Brushed system is also available

 See >>
+
