XERUN XR8 ESC Series

XERUN XR8 PLUS is another new competition ESC HOBBYWING specially develops on the basis of constant research, technical analysis and performance comparisons, for 1/8th scale professional race cars.



XR8 PLUS & SCT PRO ESC equipped w/ the following features:

High reliability & durability;

Great power output;

Super built-in BEC

Advanced electronic switch

High-efficiency heat-dissipating system

 Special dynamic timing control program

Innovative coasting function

XR8 PLUS

+


Next generation of Xerun SCT PRO ESC


XR8 SCT PRO ESC is designed for 1/8th Buggy Competition, 1/10th STC, Monster Truck, On-road, Buggy, Truggy for High-level Races

XR8 SCT PRO



Model XR8 PLUS XR8 SCT PRO Xerun SCT PRO
Cont./Peak Current 150A/950A 140A/880A 120A/760A
Motor Type Sensored / Sensorless Brushless Motor
Sensored / Sensorless Brushless Motor
Sensored / Sensorless Brushless Motor
Main Applications 1/8th Scale On-road, Buggy, Truggy for High-level Races 1/8th Buggy Competition, 1/10th Short Course Truck
Monster Truck,  On-road, Buggy, Truggy for High-level Races
1/10 and 1/8 scale short course truck / buggy / truggy
Motor Limit 4S LiPo/12S NiMH:
≤ KV3000 for 4274 size
6S LiPo/18S NiMH:
≤ KV2400 for 4274 size
2S LiPo ≤ 6000kv (36XX size)
3S LiPo ≤4000kv (36XX size)
4S LiPo ≤3000kv (36XX size)
2S LiPo ≤ 6000kv (36XX size)
3S LiPo ≤4000kv (36XX size)
4S LiPo ≤3000kv (36XX size)
LiPo/NiMH Cells (2) 3-6S LiPo, 6-18S NiMH 2-4S LiPo, 6-12Cell NiMH 2-4S LiPo, 6-12Cell NiMH
BEC Output 6V/7.2V Switchable, Continuous Current of 6A (Switch-mode BEC) 6V/7.2V Switchable, Continuous Current of 6A (Switch-mode BEC)  6V/3A (Switching mode)
Cooling Fan Powered by the stable BEC output voltage of 6V/7.2V Powered by the stable BEC output voltage of 6V/7.2V Powered by the stable BEC output voltage of 6V
Size (mm)
/Weight
58.7(L) x 48(W) x 36.9(H) / 127g (W/O Wires) 54.1(L) x 37.2(W) x 36.1(H w/fan) / 90.5g (W/O Wires) 53.5(L) x 36 (W) x 36 (H w/fan) / 90.5g (W/O Wires)
Programming Port FAN/PRG Port FAN/PRG Port FAN/PRG Port
ESC programming LCD Program box, WiFi module enabled LCD Program box, WiFi module enabled LCD Program box

$159.99
Order Now

Free Shipping

Available for pickup
Check Authorized dealer

$109.00
Order Now

Free Shipping

Available for pickup
Check Authorized dealer

$89.99
Order Now

Free Shipping

Available for pickup
Check Authorized dealer
