Hobbywing Technology

XR10 Stock Spec ESC (2S)


HOBBYWING Care Shield Plan: Opt-Out (No Shield plan)
MAP $124.99 | MSRP $177.00

ULTRA light weight -'28g'

2S LiPoSmallest Size & Lightest Weight in the world
For Stock Spec Races


  • World's Smallest footprint & Lightweight ESC ever.  "28g"
  • Innovative Double-switch Design: Built-in Electronic Switch, long life, and high reliability saves space on the chassis + Switch w/ extended wire (option)
  • Programming/Upgrading/ Data Reading Wirelessly: Integrated Data logger can record the maximum temperature of ESC and motor as well as the maximum RPM. WiFi Express Module or LCD Programming box can be used to check data easily in the pits. External Programming Port (EPP) is easy to connect and functions as a power port for an additional fan.
  • Adjustable Throttle & Brake PWM Frequencies: Independent and adjustable throttle & brake PWM frequencies guarantee precise and accurate throttle and brake control for all classes of competitions (esp. the Stock class).
  • Super Internal BEC: The built-in switch mode BEC with a maximum output of 6A and voltage adjustable between 6V and 7.4V allow the user to use various high voltage servos.
  • Multi Protection Functions makes running your ESC safe with ESC and Motor overheat protection, low voltage cutoff and throttle signal loss protection.
  • Easily programmed with the OTA programmer, Multifunction LCD Program Box, and USB Link Software.
  • XR10 Stock Spec ESC
    Current Continuous: 80A
    Burst: 380A
    Battery 5-7 cells NiMH/NiCd
    2S LiPo
    Built-in BEC 6V / 7.4V (switch mode)
    Motor Supported Sensored and sensorless brushless motors
    Suitable Motor 3650 Motors
    1/10 Touring Cars ≥10.5T,
    1/10 Buggy≥13.5T
    Application STOCK class of 1/10th Touring Car & Buggy Racing
    Cooling Fan 6V - 7.4V
    Wires 14AWG-200mm
    Size 31.5x25.6x16.1mm
    Weight** 28g
    * For 7-9 cells NiMH/NiCd or 3S LiPo, the standard cooling fan must be changed to 12V high voltage fan.
    ** Weight is w/o wires, cooling fan


    Combo Available
    For detail information, please read the user manual.

     User Manual

    Highly Recommended Accessories:

    << learn more
