80060170
Product catalog > Skywalker V2.pdf
Learn more > Skywalker ESC series
Specifications:
| p/n | 80060170 | 30205150 | 80060010 | 30205200 | 30205351 | 80060022 | 80060442 | 30216400 | 30216101 | 80060440 | 80060441 | 80060442 |
| Model | 12AE | 15A V2 | 20A | 20A V2 | 30A V2 | 40A V2 | 50A V2 | 50A V2 Plus |
60A V2 | 80A V2 | 100A V2 | 120A V2 |
| Cont.Current | 12A | 15A | 25A | 20A | 30A | 40A | 50A | 50A | 60A | 80A | 100A | 120A |
| Peak.Current |
15A | 30A | 25A | 40A | 50A | 60A | 70A | 70A | 80S | 100A | 120A | 150A |
| Input Vol (Lipo) | 2-3S | 2-3S | 2-3S | 2-3S | 3-4S | 3-4S | 3-4S | 3-6S | 3-7S | 3-6S | 3-6S | 3-8S |
| BEC Output | 5V@2A (Linear mode) | 5V@2A (Linear mode) | 5V@2A (Linear mode) | 5V@3A (Linear mode) | 5V@3A (Linear mode) | 5V@5A (Switch-mode) | 5V@5A (Switch-mode) | 5V@6A (Switch-mode) | 5V@7A (Switch-mode) | 5V@7A (Switch-mode) | 5V @ 7A (Switch-mode) | Switch Mode:5V/6V/7.4V/8.4V |
| Size (mm) | 38x18x7 | 38x17x5 | 42x25x8 | 45x23x8 | 60x25x8 | 60x25x8 | 60x25x8 | 73x30x12 | 73x30x12 | 85x36x9 | 85 x 36 x 9 | 83x35x22 |
| Weight (g) | 19 | 10 | 37 | 19 | 33 | 36 | 36 | 68 | 68 | 79 | 92 | 117 |
| Wires input | 20AWG-100mm | 18AWG-100mm | 18AWG-100mm | 16AWG-100mm | 14AWG-100mm | 14AWG-100mm | 14AWG-100mm | 14AWG-100mm | 12AWG-100mm | 12AWG-150mm | 10AWG-150mm* | 10AWG-150MM |
| Wires output | 20AWG-100mm | 20AWG-100mm | 18AWG-75mm | 18AWG-75mm | 16AWG-75mm | 16AWG-75mm | 16AWG-75mm | 14AWG-100mm | 14AWG-100mm | 14AWG-100mm | 12AWG-100mm | 12AWG-100MM |
| Output connectors | N/A | 2.0 Gold Connectors (Female) | 3.5 Gold Connectors (Female) | 3.5 Gold Connectors (Female) | 3.5 Gold Connectors (Female) | 3.5 Gold Connectors (Female) | 3.5 Gold Connectors (Female) | None | None | 4.0 Gold Connectors (Female) | 4.0 Gold Connectors (Female) | 4.0 Gold Connectors (Female) |
| Programming | Stick / LED program box | Stick / LED program box | Stick / LED program box | Stick / LED program box | Stick / LED program box | Stick / LED program box | Stick / LED program box | Stick / LED program box | Stick / LED program box | Stick / LED program box | LED program box | |
| Firmware update | N | N | N | N | N | N | N | N | N | N | N | N |
Max motor limit:
v1: 210000rpm for 2 Poles BLM*, 70000rpm for 6 poles BLM*, 35000rpm for 12 poles BLM*
*BLM = BrushLess Motor
