Platinum 180A HV V5 ESC - HOBBYWING North America

Specifications

Telemetry Function: Mikado VBar；Futaba S.Bus2；MSH iKon；Brain and etc.

Model	180A HV
p/n	30209103
Application	550-700 class electric helicopter (main rotor length 550-700mm),or fixed-wing
Input (V) Lipo	6-14S
Cont./Peak Current (10s)	180A/260A
BEC (Switch mode)	5-12V adjustable (step: 0.1V) 10A/30A Cont./Peak
Separate Programming Port	Tunalyzer / LCD Program Box / OTA Programmer
Input wires	Red-10AWG-150mm Black-10AWG-150mm
Output wires	Black-10AWG-100mm
Output connector	Gold connector
Mounting-holes	M3, 16.5* 90x34mm
size	100.6 x 45.5 x 26.1 mm
Weight	250.6g (Without Fan)
