QUICRUN BRUSHED SYSTEM

Features

Water-proof and dust-proof for all-weather races.

Want to drive during tough weather like pro racers? With our QucRUN brushed series, you no longer need a traditional waterproofing box. Our ESC is completely waterproofed so that you can save not only space in the compartment but also the weight of the vehicle.

Multiple protections

Low voltage cut-off protection for battery / Over-heat protection / Throttle signal loss protection

Jumper

The "Battery Type" and "Running Mode" can be programmed by jumpers. Battery Type: Lipo or NiMH.
Running Mode: Fwd/Br, Fwd/Rev/Br or Fwd/Rev (Fwd =Forward, Br=Brake, Rev=Reverse).

QuicRun Brushed	WP1625 BRUSHED All-purpose	WP1060 BRUSHED All-purpose	WP0880 BRUSHED Dual mode	WP1080 BRUSHED RockCrawler
p/n	30120000	30120201	30120301	30120202
Waterproof	Yes	Yes	Yes	Yes
Dual Mode	No	No	Yes	No
Fwd Cont. / Peak Rev Cont. / Peak	25A / 100A 25A / 100A	60A / 360A 30A / 180A	80A /400A 30A / 180A	80A / 400A 40A / 200A
Fwd / Rev Resistance	0.003Ω / 0.003Ω	0.001Ω / 0.002Ω	0.001Ω / 0.002Ω	0.001Ω / 0.002Ω
Car Applicable	1/18 &1/16 Touring Car, Buggy, Monster, Truggy	1/10 Touring Car, Buggy, Short Course Truck, Monster, Truggy, Rock Crawler and Tank	1/8 - 1/10 Touring Car, Buggy, Short Course Truck, Monster, Truggy, Rock Crawler and Tank or Boat	1/8 - 1/10 Rock Crawler and Tank or Boat
Motor Limit	Brushed motors (280/370/380 Size) 2S Lipo or 6 NiMH Motor RPM<30000 @7.2V 3S Lipo or 9 NiMH Motor RPM<20000 @7.2V	Brushed motors (540/550 Size) 2S Lipo or 6 NiMH Motor: ≥12T Or RPM<30000 @7.2V 3S Lipo or 9 NiMH Motor: ≥18T Or RPM< 20000 @7.2V	Brushed Motor (540, 550, 775 Size Motor) Brushed Motor Limit with 2S LiPo /6S NiMH: ≥ 12T or RPM<30000@7.4V (540, 550 Size Motors) 3S LiPo /9S NiMH: ≥ 18T or RPM<20000@7.4V (540, 550 Size Motors) 4S LiPo /12S NiMH: ≥ 24T or RPM<15000@7.4V (540, 550 Size Motors)	Brushed Motors (540/550/775 size) Limit with 2S LiPo/6S NiMH: T≥12 or RPM Limit with 3S LiPo/9S NiMH: T ≥18 or RPM< 20000 @7.2V (540/550 size motor)
Battery	2-3S Lipo or 5-9 NiMH	2-3S Lipo or 5-9 NiMH	2-4S Lipo or 5-12 NiMH	2-3S LiPo/5-9S NiMH
BEC Output	1A/6V (Linear Mode)	2A/5V (Switch Mode)	6V/4A (Switch Mode)	6V/7.4V @ 3A (switch mode)
PWM Frequency	1KHz	1KHz	Adjustable 1K/2K/4K/8K/16K	Adjustable 1K/2K/4K/8K/16K
Size/ Weight	34(L)24(W)14(H)	36.5(L)32(W)18(H)	45.934.726.5mm	36.5(L)* 32(W)*18(H) (without fan)
External Program Port	External Program Port Not Available	External Program Port Available	LED Program Box (purchase separately)	LED Program Box (purchase separately)
Cooling Fan	Without cooling fan	Without cooling fan	-	Without cooling fan
Weight*	23.5g	39g	75g	39g
