Experience Version 5

FLYFUN Series ESC for advanced airplane pilots（RoHS Compliant）

FLYFUN V5 ESC Series (6-14s)

V5 ESC is programmable by LED program card (purchase separately) or Transmitter


	160A HV OPTO V5	130A HV OPTO V5	110A OPTO / SBEC
p/n	30201650	30201500	30201700 / 30201701
Cont./Peak Current	160A/200A	130A/160A	110A/140A
Input	6-14S LiPo	6-14S LiPo	6-14S LiPo
BEC	NO	NO	Switch Mode: 5.2V/6V/7.4V,10A/25A OPTO: NO
Input /output wire	10AWG-150mm	10AWG-150mm	10AWG - 150mm
Input connector	NO	NO	NO
Output connector	NO	NO	NO
Size	110x50.3x33.3mm	110x50.3x33.3mm	92.7x45.6x27mm
weight	221.5g	221.5g	180g:SBEC 170g: OPTO
	$179.99 Free Shipping Available to Ship within 24 hours Available for pickup Check authorized dealer	$136.99 Free Shipping Available to Ship within 24 hours Available for pickup Check authorized dealer	Starts at $115.99 Free Shipping Available to Ship within 24 hours Available for pickup Check authorized dealer

V5 ESC is programmable by LED program box (purchase separately) or Transmitter


	120A V5	80A V5	60A V5	40A V5
p/n	30201400	30214201	30214101	30214002
Cont./Peak Current	120A/150A	80A/100A	60A/80A	40A/60A
Input	3-8S LiPo	3-8S LiPo	3-6S LiPo	3-6S LiPo
BEC	Switch Mode: 5.2V/6V/7.4V, 8A/20A	Switch Mode: 5.2V/6V/7.4V, 8A/20A	Switch Mode: 5.2V/6V/7.4V, 8A/20A	Switch Mode: 5.2V/6V/7.4V, 8A/20A
Input /output wire	12AWG-150mm	12AWG-150mm	14AWG-150mm	14AWG-100mm 16AWG-1=75mm
Input connector	NO	NO	NO	NO
Output connector	4.0 Gold Connectors (Female)	4.0 Gold Connectors (Female)	4.0 Gold Connectors (Female)	3.5 Gold Connectors (Female)
Size	77.2x34.6x19.2mm	69.8x34.6x19.2mm	68.8x34.6x18mm	472814
weight	93g	92g	73.5g	44g
	$89.99 Free Shipping Available to Ship within 24 hours Available for pickup Check authorized dealer	$62.99 Free Shipping Available to Ship within 24 hours Available for pickup Check authorized dealer	$52.99 Free Shipping Available to Ship within 24 hours Available for pickup Check authorized dealer	$32.99 Free Shipping Available to Ship within 24 hours Available for pickup Check authorized

V5 ESC is programmable by LED program box (purchase separately) or Transmitter


	30A V5	30A V5 Mini	20A V5
p/n	30202306	30202307	30202308
Cont./Peak Current	30A/50A	30A/45A	20A/30A
Input	2-4S LiPo	2-4s LiPo	2-4s LiPo
BEC	Switch Mode: 5.1V/6.0V, 3A/7A	Switch Mode: 5.2V, 3.5A/5A	Switch Mode: 5.2V, 2.5A/4A
Input /output wire	16AWG-100mm / 16AWG-75mm*3	16AWG-140mm / 16AWG-110mm 3mm	18AWG-140mm / 16AWG-110mm 3mm
Input connector	NO	NO	NO
Output connector	3.5mm Gold Connectors (Female)	3mm Gold Connectors (Female)	2mm Gold Connectors (Female)
Size (mm)	50x25x12mm	37x17x5mm	25x15x5mm
weight (g)	32g	23g	13g
	$23.99 Free Shipping Available to Ship within 24 hours Available for pickup Check authorized dealer	$20.99 Free Shipping Available to Ship within 24 hours Available for pickup Check authorized dealer	$15.99 Free Shipping Available to Ship within 24 hours Available for pickup Check authorized dealer
